1.5kW MM152 Middle Inertia - Nidec Sankyo S-FLAG AC Servo Motor & Drive (Complete Set)

   1.5kW AC Servo Driver, Model: DA26B (Single-Axis)

  • Basic Specification:
    • 16-Axis (Daisy-Chain) RS-485 Communication
    • I/O Positioner (15 Point Table) & Pulse Train Control Mode
    • Support Software "S-TUNE" (Free Download)
    • Main Power: 3-Phase 200V
    • Control Power: 24VDC



   1.5kW AC Servo Motor, Model: MM152N2LN (No Brake)

  • Basic Specification:
    • Frame Size: 130x130mm
    • Rate Speed: 2000 (3000 Max.) rpm
    • Rate Torque: 7.16 (21.50 Max.) Nm
    • Rotor Inertia: 6.67x10^-4 kgm^2
    • Weight: 7 kg



   1.5kW AC Servo Motor,  Model: MM152A2LN (With Brake)

  • Basic Specification:
    • Frame Size: 130x130mm
    • Rate Speed: 2000 (3000 Max.) rpm
    • Rate Torque: 7.16 (21.50 Max.) Nm
    • Rotor Inertia: 8.35x10^-4 kgm^2
    • Weight: 8.4 kg
